Contact for Price
Specifications
| RV Type | Tent Trailer | Stock No | 26VL004 |
| Status | New | Length | 17.3 ft. |
| Weight | 2500 lbs. | Lot Location | Edmonton |
Key Specifications Specification Details Length (closed) 15 ft 5 in Length (open) 17 ft 3 in Exterior Width 6 ft 6 in Exterior Height (closed) 4 ft 10 in (without A/C) Exterior Height (open) ~8 ft 6 in Unloaded Vehicle Weight (UVW) 1,397 lbs Gross Vehicle Weight Rating (GVWR) 2,500 lbs Cargo Carrying Capacity (CCC) ~1,103 lbs Number of Slides 0 Sleeps Up to 3 Hitch Weight ~140 lbs Fresh Water Capacity 11 gallons Gray Water Capacity N/A (no sink drain) Black Water Capacity N/A (portable toilet) LP Tanks One 20 lb tank Axles Single Tires ST175/80R13 radial
Note: Weights and capacities are based on standard build; actual values may vary with options like A/C, dormers, or lift kit. Verify with a dealer for exact GVWR and towing compatibility.
Floorplan LayoutThe Scout’s open A-frame design creates a tent-like interior with high ceilings and excellent ventilation via four screened panoramic windows:
- Front Bunk: 30" x 76" fixed bunk with 3" foam mattress (sleeps 1 adult or child); overhead storage shelf.
- Rear Dinette/Living: 46" x 76" convertible dinette (seats 4, sleeps 2) with removable table; folds flat into a full bed.
- Kitchenette: Rear corner with single stainless sink, manual water pump, and countertop; optional two-burner flush-mount cooktop and 1.7 cu. ft. 12V fridge.
- Bathroom: None built-in; uses portable cassette toilet (stored in exterior bag door compartment).
- Entry: Two side doors (one to front bunk, one to dinette) with bug screens and privacy curtains.
When open, the interior offers ~100 sq ft of usable space with a peak height of 6 ft 6 in, ideal for standing and moving comfortably.
Interior FeaturesFocused on lightweight essentials with clean, durable materials:
- Kitchen: Manual water pump (electric optional), single sink, optional cooktop and mini-fridge; storage cabinets.
- Living Space: LED interior lighting, 110V/USB outlets, vinyl flooring, and Azdel walls for insulation and sound dampening.
- Climate Control: Optional 5,000 BTU wall-mounted A/C or 13.5K BTU roof A/C; fan vent; no furnace standard (optional 16K BTU propane heater).
- Storage: Overhead shelves, under-dinette bins, and exterior bag door for toilet/gear.
Built for portability and rugged simplicity:
- Roof & Shell: Gray fiberglass hard sides, one-piece design; optional front soft dormer for extra headroom.
- Awning: Optional 8 ft manual side awning.
- Convenience: Exterior bag door (for toilet/storage), manual tongue jack, rear stabilizer jacks, and roof rack prep.
- Off-Road/Setup: High ground clearance (~16 in closed), optional high-wind lift assist kit, electric brakes, and spare tire mount.
- Power: 30-amp shore power inlet with 20-amp converter; optional 100W roof-mounted solar panel.
All prices plus GST.
Disclaimer: All information, including but not limited to, pricing, product information, specifications, media and dealer promotions are subject to change without notice.
